Minebea C2G1-30K-A Load Cell (30kg) – Cantilever Beam Type
The Minebea C2G1-30K-A load cell (30kg capacity) is a compact cantilever beam-type force sensor designed for low-profile scales and light industrial weighing systems. As part of the well-known C2G1 series by Minebea (NMB Japan), this model offers excellent accuracy, stability, and mechanical strength.
If you are looking specifically for the “30kg Cantilever Beam Load Cell – Minebea C2G1-30K-A”, the information below provides complete specifications, features, and applications.
Key Features of the C2G1-30K-A
- Cantilever beam design – easy installation and compatible with many weighing systems.
- High accuracy suitable for commercial and industrial light-load weighing.
- OIML certified for stable and reliable measurement performance.
- 150% safe overload capability, ensuring excellent durability.
- Lightweight aluminum body, ideal for low-profile scales.
- Standard output of 2.0 mV/V – compatible with most Minebea Intec indicators and amplifiers.
Technical Specifications – Minebea C2G1-30K-A
| Model |
C2G1-30K-A |
| Capacity |
30 kg |
| Rated Output |
2.0 mV/V ±0.2 mV/V |
| Non-linearity |
0.015 % R.O. |
| Hysteresis |
0.015 % R.O. |
| Repeatability |
0.02 % R.O. |
| Creep (20 min) |
0.02 % R.O. |
| Input Resistance |
≈ 420 Ω |
| Output Resistance |
≈ 350 Ω ±5 Ω |
| Excitation |
Recommended ≤ 12 V – Max 20 V |
| Protection |
IP64 |
| Operating Temperature |
-10°C to 50°C |
| Material |
Aluminum |
| Cable |
4-core shielded cable, 40 cm |
Applications of the C2G1-30K-A
- Bench scales and platform scales (30kg).
- Low-profile industrial scales.
- Light-load checkweigher systems.
- Automatic packaging and dosing equipment.
- Embedded weighing modules for OEM machinery.
Why Buy from Quoc Hung?
- Genuine Minebea products with full documentation (Invoice & Packing List).
- Professional support for selection, wiring, calibration, and installation.
- Fast delivery and warranty according to Minebea standards.
